Gosafe protocol is supported in flespi telematics hub. Supported devices are below Gosafe G6S Gosafe G3SC Gosafe G3A Gosafe G3C Gosafe G6C Gosafe G737 Gosafe G1S

Gosafe protocol updated: parsing of the following Event IDs is added for Event data (ETD) field: 0: Tow - flespi parameter towing.alarm.status 1: Idle - - flespi parameters idle.status and idle.status.duration 2: Parking - flespi parameter movement.status 3: Speed - flespi parameter overspeeding.status 4: GSM jamming - flespi parameter gsm.jamming.alarm.status 5: Geo-fence - flespi parameter geofence.alarm 8: Harsh brake - flespi parameters harsh.braking.event and brake.acceleration 9: Harsh accelerate - flespi parameters harsh.acceleration.event and absolute.acceleration 10: Harsh turn - flespi parameters harsh.cornering.event and turn.acceleration 11: Front-end collision - flespi parameter front.collision.event 12: Rear-end collision - flespi parameter rear.collision.event 13: Turnover - flespi parameter turnover.event

Gosafe protocol updated: fixed parsing of GPS data > GPS fix flag and valid satellite number fields for HEX protocol added parsing of Event 55 Hardware malfunction for ASCII protocol. The following parameters are registered: hardware.malfunction.alert=true hardware.fault.code

[Changelog] gosafe protocol

namo

Gosafe protocol is supported in flespi telematics hub.

Gosafe

Supported devices are below

namo

Gosafe protocol is updated: IBC data type is supported. Parameter ibutton.code is registered for this data type.

baja

integer parameter position.fix.type showing if the position is 2D (value = 1), 3D (value = 2) or not fixed (value = 0) added

namo

Gosafe protocol updated: event data block ETD supported for ASCII protocol format.

baja

Parameter can.vehicle.vin will be renamed to vehicle.vin
Both parameters will be registered for 2 weeks until 10 March, 2020. Then can.vehicle.vin will be removed

baja

baja Parameter can.vehicle.vin removed

namo

Gosafe protocol updated: added parsing of OBD data and Fuel data fields for ASCII protocol.

namo

Gosafe protocol updated: parsing of the following Event IDs is added for Event data (ETD) field:

0: Tow - flespi parameter towing.alarm.status
1: Idle - - flespi parameters idle.status and idle.status.duration
2: Parking - flespi parameter movement.status
3: Speed - flespi parameter overspeeding.status
4: GSM jamming - flespi parameter gsm.jamming.alarm.status
5: Geo-fence - flespi parameter geofence.alarm
8: Harsh brake - flespi parameters harsh.braking.event and brake.acceleration
9: Harsh accelerate - flespi parameters harsh.acceleration.event and absolute.acceleration
10: Harsh turn - flespi parameters harsh.cornering.event and turn.acceleration
11: Front-end collision - flespi parameter front.collision.event
12: Rear-end collision - flespi parameter rear.collision.event
13: Turnover - flespi parameter turnover.event

baja

The protocol will be affected by the change in type of parameters gsm.mcc and gsm.mnc to be installed in 2 weeks - May 23rd, 2022: both parameters that now have type "string" will be stored as "number". The possible leading zeroes in MNC will be ignored (e.g. the value "01" will be stored as 1).

namo

Gosafe protocol updated:

fixed parsing of GPS data > GPS fix flag and valid satellite number fields for HEX protocol
added parsing of Event 55 Hardware malfunction for ASCII protocol. The following parameters are registered:
- hardware.malfunction.alert=true
- hardware.fault.code
